^XS — Dynamic Media Calibration

Goal

Calibrate media dynamically with ^XS.

Description

^XS enables dynamic media calibration on G-Series printers: length and threshold tracking (Y/N each) after power-up or head-open. (It does not save formats — that is ^DF, lesson 47.)

Example

^XA
^XSY,Y
^FX Dynamic length and threshold calibration enabled.
^FO20,20^A0N,28,28^FDFresh calibration^FS
^XZ

Result

Calibration enabled; the printing itself is an ordinary text field.
